4/3 directional spool valve size 6, 220 V DC, spool E, 4WE6E6X/EG220N9K4 - Bosch Rexroth R900933503
For size 6 hydraulic circuits with up to 350 bar and 80 l/min flow: the directional valve 4WE6E6X/EG220N9K4 routes oil between 4 ports. The solenoid runs on 220 V DC and connects via an EN 175301-803 connector, seals are made of NBR. Weight 1.95 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The spool inside the directional valve 4WE6E6X/EG220N9K4 determines which of the 4 ports are connected, and it is shifted by a 220 V DC solenoid. The version is selected via the spool symbol, here E. The ISO 4401-03-02-0-05 hole pattern of the 4WE6E6X/EG220N9K4 fits standard size 6 subplates.
Benefits
- Pressure rated to 350 bar at size 6.
- Flow up to 80 l/min for brisk actuator motion.
- Interchangeable thanks to the ISO 4401-03-02-0-05 pattern.
- 220 V DC solenoid, EN 175301-803 connector.
- NBR seals matched to the approved hydraulic fluids.
- UKCA compliant under SI2016/1101.
Applications
The 4WE6E6X/EG220N9K4 is used in machine building and industrial hydraulics wherever a cylinder or motor has to change direction under electrical control. A replacement needs the same spool symbol E and the same voltage.
Technical data
| Type | 4WE6E6X/EG220N9K4 |
|---|---|
| Material number | R900933503 |
| Size | 6 |
| Maximum operating pressure | 350 bar |
| Maximum flow | 80 l/min |
| Connection diagram | ISO 4401-03-02-0-05 |
| Type of actuation | Solenoid actuation |
| Spool symbol | E |
| Number of switching positions | 3 |
| Number of ports | 4 |
| Seals | NBR |
| Hydraulic fluid | HL, HLP, HLPD, HVLP, HVLPD and HFC |
| Supply voltage | 220 V DC |
| Electrical connection | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Conformity | UKCA (Low-Voltage Directive SI2016/1101) |
| Weight | 1.95 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | R900933503 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Seal material | NBR |
| Function | 4/3 |
| Flow rate [l/min] | 80 |
| Design | Piston pusher |
| Actuation type | Electrical |
| Norm | ISO 4401 |
| Betriebsdruck max [bar] | 350 |
Approved for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD and HFC, sealed with NBR.
