Directional Spool Valve Z4WEH16E63-5X/6EG24N9ETK4/B10D3 - Bosch Rexroth R900925289

Name: Directional Spool Valve Z4WEH16E63-5X/6EG24N9ETK4/B10D3 - Bosch Rexroth R900925289
Brand: Bosch Rexroth
SKU: BRR-R900925289
Price: 3414.56 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

If the connection diagram matches, a sandwich plate can be inserted into an existing stack. The Z4WEH16E63-5X/6EG24N9ETK4/B10D3 works to ISO 4401-07-07-0-05, releases up to 300 l/min and switches at 24 VDC with 315 bar.

Net

€3,414.56

excl. VAT

Item BRR-R900925289

Manufacturer no. R900925289

Question about this item

Datasheet (PDF) User manual 9 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A manifold stack only grows cleanly when every plate follows the same connection diagram. The Z4WEH16E63-5X/6EG24N9ETK4/B10D3 keeps to ISO 4401-07-07-0-05 and brings symbol E63 into the stack at 300 l/min.

Benefits

Connection diagram ISO 4401-07-07-0-05, matching existing size 16 stacks
Symbol E63 in two switching positions across four ports
Flow of up to 300 l/min at an operating pressure of no more than 315 bar
NBR seals for HL hydraulic fluid
Solenoid control at 24 VDC from the plant control
15.7 kg mass as a planning figure for the stack assembly

Application

It is installed in manifolds of presses, rolling mills and large power units. When a function is added later, only a matching connection diagram decides whether the plate can join the stack without rework.

Manufacturer

Bosch Rexroth lists this directional spool valve Z4WEH16E63-5X/6EG24N9ETK4/B10D3 under material number R900925289. Manufacturer datasheets are available for this item.

Technical data

Connection diagram	ISO 4401-07-07-0-05
Max. flow	300 l/min
Product family	Z.WEH16
Type of connection	Sandwich plate
Supply voltage	24 VDC
Number of switching positions	2
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector 3-pole (2 + PE) according to EN 175301-803
Spool symbol	Symbol E63
Operating pressure, max.	315 bar
Size	16
Seals	NBR
Electrical connector	Connector, 3-pole (2 + PE)
Type of actuation	with solenoid actuation
Weight	15.7 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R900925289
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
