4/2 directional spool valve size 6, 205 V DC, spool D, 4WE6D6X/EG205N9K4/B12 - Bosch Rexroth R900925178
For size 6 hydraulic circuits with up to 350 bar and 70 l/min flow: the directional valve 4WE6D6X/EG205N9K4/B12 routes oil between 4 ports. Solenoid actuation at 205 V DC, EN 175301-803 connector and NBR seals, spool symbol D. Weight 1.8 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
In the 4WE6D6X/EG205N9K4/B12, a 205 V DC solenoid switches the oil flow in a size 6 hydraulic circuit, with operating pressure up to 350 bar. Spool symbol D shows which paths are open in the 2 switching positions. The 4WE6D6X/EG205N9K4/B12 mounts on a subplate with the ISO 4401-03-02-0-05 hole pattern.
Benefits
- Pressure rated to 350 bar at size 6.
- 70 l/min flow at size 6.
- ISO 4401-03-02-0-05: standard mounting pattern.
- Electrical connection: EN 175301-803 connector, 205 V DC.
- NBR seals matched to the approved hydraulic fluids.
- UKCA compliant under SI2016/1101.
Applications
The 4WE6D6X/EG205N9K4/B12 suits presses, clamping fixtures, machine tools and hydraulic power units. On replacement, hole pattern and wiring stay the same.
Technical data
| Type | 4WE6D6X/EG205N9K4/B12 |
|---|---|
| Material number | R900925178 |
| Size | 6 |
| Maximum operating pressure | 350 bar |
| Maximum flow | 70 l/min |
| Connection diagram | ISO 4401-03-02-0-05 |
| Type of actuation | Solenoid actuation |
| Spool symbol | D |
| Number of switching positions | 2 |
| Number of ports | 4 |
| Seals | NBR |
| Hydraulic fluid | HL, HLP, HLPD, HVLP, HVLPD and HFC |
| Supply voltage | 205 V DC |
| Electrical connection | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Conformity | UKCA (Low-Voltage Directive SI2016/1101) |
| Weight | 1.8 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | R900925178 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Seal material | NBR |
| Function | 4/2 |
| Flow rate [l/min] | 70 |
| Design | Piston pusher |
| Actuation type | Electrical |
| Norm | ISO 4401 |
| Betriebsdruck max [bar] | 350 |
Approved for hydraulic fluids HL, HLP, HLPD, HVLP, HVLPD and HFC, sealed with NBR.
