With a setting range of 4 to 180 bar and 230 l/min rated flow, this version covers circuits with high volume and moderate pressure. The weight is 4.88 kg and the maximum operating pressure is 350 bar.
Pressure Relief Valve DBW10B2-5X/180YS6EG24N9K4R12E - Bosch Rexroth R900788022
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,393.08
Item
BRR-R900788022
Manufacturer no.
R900788022
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900788022
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900788022
Frequently Bought Together
-
This Item:
€1,393.08
-
Druckzuschaltventil DZ20-2-5X/50XY - Bosch Rexroth R900509123
€1,187.06
-
Pressure Relief Valve DBGT-1X/100E1-673 - Bosch Rexroth R900553590
€9,038.97
Total price
Large cylinders at moderate pressure move a lot of oil, and exactly that case drives the rating here. The valve discharges up to 230 l/min and can be set in the range from 4 to 180 bar, well below the maximum operating pressure of 350 bar.
Benefits
- 230 l/min rated flow for circuits with large oil volumes
- Setting range 4 to 180 bar for moderate working pressures
- 350 bar maximum operating pressure of the body as reserve against pressure peaks
- Pilot-operated poppet valve, internal hexagon with protective cap
- 4.88 kg weight, subplate mounting to ISO 6264-06-09
Technical data
| Connection diagram | ISO 6264-06-09 |
| Max. flow | 230 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Conformity | CE |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | B |
| Operating pressure, max. | 350 bar |
| Size | 10 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 4.88 kg |
Applications
The valve suits lifting units and feed drives with large cylinder areas that work at low pressure. The body reserve up to 350 bar absorbs pressure peaks that can occur when driving against an end stop. Electrical unloading runs on 24 V DC.
Manufacturer
Bosch Rexroth, material number R900788022. Dimensional drawings, characteristic curves and ordering data are in data sheet RE 25802 and RE 25802-B.
| Hersteller-Nr | R900788022 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 4.880000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
