Pressure Relief Valve DBW30A3N5X/200S6EG24N9K4R12 - Bosch Rexroth R900761302
Unloading this valve electrically takes no more than a 24 V line and a device connector to EN 175301-803. The DBW30A3N5X/200S6EG24N9K4R12 limits pressure across 4 to 200 bar and passes up to 650 l/min in size 32.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A single switching command on the mounted solenoid unloads the circuit, wired through a three-pole device connector to EN 175301-803. The valve limits pressure across 4 to 200 bar, relieves up to 650 l/min and carries spool symbol A.
Benefits
- Electrical unloading at 24 VDC through a 3-pole connector (2 + PE) to EN 175301-803
- Adjustment range of 4 to 200 bar at a maximum operating pressure of 350 bar
- 650 l/min relief capacity in size 32 to ISO 6264-10-17
- Lockable rotary knob with a scale, pilot stage in seat design
- Spool symbol A with two switching positions
- Subplate mounting, NBR seals, weight 7 kg
Applications
The valve sits in power units whose control system unloads the pump during start-up and breaks. The standard device connector allows quick disconnection for maintenance. An adjustment range of 4 to 200 bar covers the usual system pressure of medium sized units.
Manufacturer
Bosch Rexroth lists this valve in product family DB.10-30 under material number R900761302. Characteristic curves and installation dimensions are held in data sheet RE 25802, supplemented by RE 25802-B.
Technical data
| Connection diagram | ISO 6264-10-17 |
|---|---|
| Max. flow | 650 l/min |
| Product family | DB.10-30 |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Connector, 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | A |
| Operating pressure, max. | 350 bar |
| Size | 32 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 7 kg |
| Manufacturer | Bosch Rexroth |
| Hersteller-Nr | R900761302 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
