NBR seals and the release for HL determine which oil may run in the circuit. The 4WEH32E6X/6EG24N9ETSK4/B10 is built that way and controls up to 1100 l/min at 280 bar in size 32. Spool symbol E, mass 36.9 kg.
Directional Spool Valve 4WEH32E6X/6EG24N9ETSK4/B10 - Bosch Rexroth R900712486
BOSCH REXROTH
Original product
Net price (excl. VAT)
€3,728.37
Item
BRR-R900712486
Manufacturer no.
R900712486
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900712486
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900712486
Frequently Bought Together
-
This Item:
€3,728.37
-
Directional Spool Valve 4WE 6 M6X/EG24NK4/B12V/62 - Bosch Rexroth R978913428
€271.55
-
Directional Spool Valve Z4WEH10X161-4X/6EG24ETK4/B10SO4 - Bosch Rexroth R901489918
€2,982.73
Total price
Sealing material and hydraulic fluid have to match, otherwise the circuit ages early. The 4WEH32E6X/6EG24N9ETSK4/B10 works with NBR seals and hydraulic fluid HL at up to 1100 l/min.
Benefits
- NBR seals for operation with hydraulic fluid HL.
- 1100 l/min maximum flow at 280 bar maximum operating pressure.
- Spool symbol E in three switching positions with four ports.
- Internal pilot oil supply and internal pilot oil return without separate control lines.
- 36.9 kg mass, subplate mounting to ISO 4401-10-09-0-05, 24 V DC.
Technical data
| Connection diagram | ISO 4401-10-09-0-05 |
| Max. flow | 1100 l/min |
| Product family | H-4W.H.. |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | Symbol E |
| Operating pressure, max. | 280 bar |
| Size | 32 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 36.9 kg |
Applications
The field of use covers power units with mineral oil of group HL, as common in presses, test rigs and production plants. Before using other fluids the sealing material has to be checked. The pilot-operated design keeps the solenoid power small.
Manufacturer
Bosch Rexroth, material number R900712486, product family H-4W.H... Permissible hydraulic fluids and temperature ranges are given in data sheet RE 24751.
| Hersteller-Nr | R900712486 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 36.900000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
