Proportional Directional Valve 4WRTE10V100L-4X/6EG24K31/F1M - Bosch Rexroth R900704386

Name: Proportional Directional Valve 4WRTE10V100L-4X/6EG24K31/F1M - Bosch Rexroth R900704386
Brand: Bosch Rexroth
SKU: BRR-R900704386
Price: 5433.29 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

When replacing a proportional valve, the spool symbol has to match the existing control. This 4WRTE10V100L has symbol V, 100 l/min nominal flow and a 4...20 mA command value at 350 bar operating pressure.

Net

€5,433.29

excl. VAT

Item BRR-R900704386

Manufacturer no. R900704386

Question about this item

Datasheet (PDF) User manual 10 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For a replacement in a running plant, spool symbol, nominal flow and command signal type all have to line up. The 4WRTE10V100L-4X/6EG24K31/F1M combines symbol V with 100 l/min nominal flow and a 4...20 mA current command value.

Benefits

Spool symbol V, linear relation between command value and flow
Nominal flow 100 l/min, maximum flow 170 l/min
4...20 mA command value, connects to current outputs of the controller without adaptation
External pilot oil supply and external pilot oil return
Maximum operating pressure 350 bar, internal spool position feedback

Application

For replacement and new build of axes with a 100 l/min demand and a current command signal. Pilot oil is fed and returned externally, which requires a dedicated pilot line. Size 10 to ISO 4401-05-05-0-05, weight 8.47 kg.

Manufacturer

Bosch Rexroth, material number R900704386, type 4WRTE10V100L-4X/6EG24K31/F1M.

Technical data

Connection diagram	ISO 4401-05-05-0-05
Max. flow	170 l/min
Product family	4WRTE
Type of connection	Subplate mounting
Nominal flow	100 l/min
Supply voltage	24 VDC
Connectivity	Analog, command value 4...20 mA
Number of switching positions	3
Hydraulic fluid	HL
Number of ports	4
Electrical connection description	Connector, 7-pole (6 + PE) according to EN 175201-804
Spool symbol	Symbol V
Operating pressure, max.	350 bar
Size	10
Seals	NBR
Electrical connector	Connector, 7-pole (6 + PE)
Type of actuation	Electrical with on-board electronics
Weight	8.47 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R900704386
Zolltarifnummer	84812010
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
