Variable displacement vane pump size 45 cm³, 66 l/min, 160 bar, clockwise rotation, FKM, PV7-1X/40-45RE37KD0-16 - Bosch Rexroth R900701362

Bosch Rexroth ✓ Original product Brand new Made in Germany

Variable displacement vane pump PV7-1X/40-45RE37KD0-16 in size 45 cm³: up to 66 l/min flow, operating pressure up to 160 bar. It controls precisely thanks to low hysteresis and high repeatability and runs with low noise and pulsation.

Net
€3,910.71
excl. VAT
Item BRR-R900701362
Manufacturer no. R900701362
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

160 bar operating pressure and up to 66 l/min: that is what the Bosch Rexroth variable displacement vane pump PV7-1X/40-45RE37KD0-16 in size 45 cm³ delivers at a weight of 28.78 kg.

Benefits

  • Max. operating pressure 160 bar
  • Max. flow 66 l/min at size 45 cm³
  • Precise control behaviour through low hysteresis and high repeatability
  • Low noise and pulsation level, flexibly combinable with other Rexroth pumps
  • 4-hole mounting flange 125B4HW according to ISO 3019-2, shaft end cylindrical Ø 32 mm with fitting key, ISO 3019-2
  • FKM seals, hydraulic fluid HETG, HEES, HFDU

Applications

In industrial hydraulic systems up to 160 bar the PV7-1X/40-45RE37KD0-16 in size 45 cm³ works as a variable displacement pump. Version with through-drive. Direction of rotation: clockwise rotation. For replacement and reordering, material number R900701362 applies.

Technical data

TypePV7-1X/40-45RE37KD0-16
Material numberR900701362
ManufacturerBosch Rexroth
Product typeVariable displacement vane pump
SeriesPV7
Size45 cm³
Displacement typevariable
Max. flow66 l/min
Operating pressure max.160 bar
Direction of rotationClockwise rotation
Mounting flange4-hole mounting flange 125B4HW according to ISO 3019-2
Shaft endCylindrical Ø 32 mm with fitting key, ISO 3019-2
Through-drivewith
SealsFKM
Hydraulic fluidHETG, HEES, HFDU
Weight28.78 kg
Hersteller-NrR900701362
Zolltarifnummer84136061
GPSR HerstellerdatenBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
Seal materialFKM
NormISO 3019-2
Betriebsdruck max [bar]160
