Some circuits need only two defined positions and no mid-position at all. The H-4WEH25HD6X/OF6EG24NSK4 works with spool symbol D in two switching positions, passes up to 700 l/min at a maximum operating pressure of 350 bar and is driven through a 3-pole connector.
Directional Spool Valve H-4WEH25HD6X/OF6EG24NSK4 - Bosch Rexroth R900617849
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,285.31
Item
BRR-R900617849
Manufacturer no.
R900617849
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900617849
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900617849
Frequently Bought Together
-
This Item:
€2,285.31
-
Directional Spool Valve 4WE 6 EA6X/EG24N9K4/62 - Bosch Rexroth R978017752
€180.24
-
Proportional Directional Valve 4WRTE16V125L-4X/6EG24K31/A1V - Bosch Rexroth R901077099
€6,342.80
Total price
A cylinder that only alternates between two end positions does without a mid-position. The H-4WEH25HD6X/OF6EG24NSK4 offers spool symbol D in two switching positions and passes up to 700 l/min in size 25.
Benefits
- Two switching positions with spool symbol D across four ports.
- 700 l/min at a maximum operating pressure of 350 bar.
- 3-pole connector (2 + PE) to EN 175301-803 for the 24 V DC solenoid actuation.
- Subplate mounting to connection diagram ISO 4401-08-08-0-05.
- 19.3 kg weight, NBR seals, hydraulic fluid HL.
Technical data
| Connection diagram | ISO 4401-08-08-0-05 |
| Max. flow | 700 l/min |
| Product family | H-4W.H.. |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | Symbol D |
| Operating pressure, max. | 350 bar |
| Size | 25 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 19.3 kg |
Application
Typical duties are reversing drives on rolls, gates and flaps that swing between two positions. External pilot oil supply and external pilot oil return keep the pilot circuit fully separate from the main circuit.
Manufacturer
Bosch Rexroth lists the valve under material number R900617849 in product family H-4W.H.., data sheets RE 24751 and RE 07600-B.
| Hersteller-Nr | R900617849 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 19.300000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
