When the pilot stage is fed from its own pressure source and drained separately, the main valve works independently of load pressure. The H-4WEH25J6X/6EG24N9S2DAL is built that way, switches 700 l/min with spool symbol J and weighs 18.47 kg.
Directional Spool Valve H-4WEH25J6X/6EG24N9S2DAL - Bosch Rexroth R900617656
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,285.03
Item
BRR-R900617656
Manufacturer no.
R900617656
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900617656
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900617656
Frequently Bought Together
-
This Item:
€2,285.03
-
Directional Poppet Valve M-3SEW6C3X/420MG24N4K4/P - Bosch Rexroth R901022188
€1,383.18
-
Directional Spool Valve 4WE6EA6X/EG24NK4QM0G24 - Bosch Rexroth R900909020
€368.94
Total price
A separate pilot supply makes the shifting time of a large directional valve predictable. The H-4WEH25J6X/6EG24N9S2DAL takes pilot oil from outside, drains it to the outside and passes up to 700 l/min in the main circuit at a maximum of 350 bar.
Benefits
- External pilot oil supply and external pilot oil return for a dedicated pilot feed.
- Spool symbol J with three switching positions across four ports.
- 700 l/min in size 25 at a maximum operating pressure of 350 bar.
- Cable gland for the 24 V DC solenoid wiring.
- 18.47 kg weight, NBR seals, connection diagram ISO 4401-08-08-0-05.
Technical data
| Connection diagram | ISO 4401-08-08-0-05 |
| Max. flow | 700 l/min |
| Product family | H-4W.H.. |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | Symbol J |
| Operating pressure, max. | 350 bar |
| Size | 25 |
| Seals | NBR |
| Electrical connector | Cable gland |
| Type of actuation | with solenoid actuation |
| Weight | 18.47 kg |
Application
Circuits like this appear where main pressure fluctuates strongly, for example on presses with changing load. A dedicated pilot circuit with 24 V DC solenoids then shifts regardless of the state of the working circuit.
Manufacturer
Bosch Rexroth lists the valve under material number R900617656 in product family H-4W.H.., data sheets RE 24751 and RE 07600-B.
| Hersteller-Nr | R900617656 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 18.469000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
