A test bench or a preload station needs a holding pressure that the machine control can set. The DBGT-1X/50VP1-673 limits pressure to the 50 bar rating and follows a command value that external electronics pass to the adjustment motor. Up to 600 l/min flow off through the subplate.
Pressure Relief Valve DBGT-1X/50VP1-673 - Bosch Rexroth R900557229
BOSCH REXROTH
Original product
Net price (excl. VAT)
€9,937.94
Item
BRR-R900557229
Manufacturer no.
R900557229
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900557229
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900557229
Frequently Bought Together
-
This Item:
€9,937.94
-
Pressure Relief Valve DBW20.2-5X/315UV - Bosch Rexroth R901407443
€816.82
-
Pressure Relief Valve DBW30B2-5X/350US6EG24N9K4R12 - Bosch Rexroth R900921275
€1,476.93
Total price
Anyone who wants to change the holding pressure from the machine program gets nowhere with a handwheel. The DBGT-1X/50VP1-673 works with the 50 bar pressure rating and takes its command value from external electronics, which drive the DC motor of the adjustment. As a pilot operated proportional pressure relief valve in poppet seat design it passes up to 600 l/min to tank.
Benefits
- 50 bar pressure rating, the whole command range spreads across that pressure window.
- DC motor adjustment with external electronics, 24 VDC supply voltage.
- 600 l/min flow at a maximum operating pressure of 315 bar.
- Poppet seat design with two ports in two switching positions, symbol A to B, X to Y.
- 6-pole mating connector (5 + PE) to EN 43651, 7-pole connector (6 + PE) on the valve.
- 5.4 kg mass, FKM seals, subplate mounting, released for HL hydraulic fluid.
Technical data
| Max. flow | 600 l/min |
| Product family | DBG |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Electrical connection description | Mating connector, 6-pole (5 + PE) according to EN 43651 |
| Spool symbol | A to B, X to Y |
| Operating pressure, max. | 315 bar |
| Seals | FKM |
| Electrical connector | Connector, 7-pole (6 + PE) |
| Type of actuation | Electrical with external electronics |
| Weight | 5.4 kg |
Application
The valve suits test benches, preload stations and laminating lines where the holding pressure is part of the sequence program. The 50 bar rating covers applications in the low pressure window. Higher settings call for a different pressure rating of the series.
Manufacturer
Bosch Rexroth, material number R900557229.
| Hersteller-Nr | R900557229 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 5.400000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
