At 9.86 kg the 4WEH16U7X/6EG24N9EK4/B10P4,5 passes a flow of 300 l/min. It carries spool symbol U, holds 280 bar maximum operating pressure and switches three positions across four ports from a 24 VDC solenoid.
Directional Spool Valve 4WEH16U7X/6EG24N9EK4/B10P4,5 - Bosch Rexroth R900247294
BOSCH REXROTH
Original product
Net price (excl. VAT)
€2,076.47
Item
BRR-R900247294
Manufacturer no.
R900247294
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R900247294
Country of originGermany
Customs tariff number84812010
ConditionNew
Artikel
BRR-R900247294
Frequently Bought Together
-
This Item:
€2,076.47
-
Directional Spool Valve 5-4WE10H5X/EG96N9K4/M - Bosch Rexroth R901530131
€420.83
-
Directional Spool Valve 4WE6H6X/EG24NJ3K4 - Bosch Rexroth R901539349
€293.35
Total price
The 4WEH16U7X/6EG24N9EK4/B10P4,5 weighs 9.86 kg and works with spool symbol U in the B10 version. Flow reaches 300 l/min and maximum operating pressure 280 bar. Subplate mounting follows the ISO 4401-07-07-0-05 pattern.
Benefits
- 9.86 kg at 300 l/min flow
- Spool symbol U in the B10 version, size 16
- 280 bar maximum operating pressure, HL hydraulic fluid
- 3 switching positions across 4 ports, ISO 4401-07-07-0-05
- 24 VDC solenoid actuation, 3-pole connector (2 + PE)
Technical data
| Connection diagram | ISO 4401-07-07-0-05 |
| Max. flow | 300 l/min |
| Product family | H-4W.H.. |
| Type of connection | Subplate mounting |
| Supply voltage | 24 VDC |
| Number of switching positions | 3 |
| Hydraulic fluid | HL |
| Number of ports | 4 |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Spool symbol | Symbol U |
| Operating pressure, max. | 280 bar |
| Size | 16 |
| Seals | NBR |
| Electrical connector | Connector, 3-pole (2 + PE) |
| Type of actuation | with solenoid actuation |
| Weight | 9.86 kg |
Application
The valve controls double-acting cylinders in presses, forges and hydraulic power units. The 9.86 kg mass has to be allowed for when sizing the subplate and the bracket. Installation dimensions and centre of gravity data are given in the data sheet.
Manufacturer
Bosch Rexroth, material number R900247294. Two manufacturer documents are on file, characteristic curves and switching times are given in the data sheet.
| Hersteller-Nr | R900247294 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 9.860000 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
