B38 Series stainless steel filter/regulator, 1/4 NPT, 25µm, 0.07-4 bar - Norgren B38-242-A2FA
Saves space because several functions sit in one body. The B38 Series stainless steel filter/regulator Norgren B38-242-A2FA is suitable for compressed air and reaches a flow of 8 dm³/s.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Air preparation units combine filtration, pressure regulation and further functions in one device. The B38 Series stainless steel filter/regulator Norgren B38-242-A2FA accepts an inlet pressure up to 17 bar and covers the temperature range -40 to 80 °C.
Benefits
- Designed for corrosive environments
- The metal parts meet NACE MR-01-75
- Port size 1/4 NPT
- Outlet pressure adjustable from 0.07 to 4 bar
- Flow 8 dm³/s
- Filtration grade 25 µm
Applications
The unit sits at the start of the air preparation ahead of valve islands, cylinders and tools.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The product conforms to NACE MR-0175, 2002 revision.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren B38-242-A2FA |
| Series | B38 |
| Standard | NACE MR-0175, 2002 revision |
| Regulator type | Precision |
| Relieving function | Relieving |
| Adjustment | Adjusting screw |
| Adjusting knob | Stainless steel |
| Port size | 1/4 NPT |
| Gauge port | 1/4 NPT |
| Maximum inlet pressure | 17 bar |
| Adjustable outlet pressure | 0.07 to 4 bar |
| Flow | 8 dm³/s |
| Filtration grade | 25 µm |
| Filter element | Polyurethane (PU) |
| Drain | Automatic |
| Bowl material | Stainless steel |
| Bowl type | Metal |
| Medium | Compressed air |
| Temperature range | -40 to 80 °C |
| Body material | Stainless steel |
| Spring bonnet | Stainless steel |
| Seal material | Synthetic rubber |
| Country of origin | China |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | B38-242-A2FA |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
