B07 Series filter/regulator, 1/4 NPT, 5µm, 0.3-10 bar, manual drain, without gauge - Norgren B07-205-M1MA
Saves space because several functions sit in one body. The B07 Series filter/regulator Norgren B07-205-M1MA is suitable for compressed air and filters at a grade of 5 µm.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Air preparation units combine filtration, pressure regulation and further functions in one device. The B07 Series filter/regulator Norgren B07-205-M1MA reaches a flow of 6.5 dm³/s and filters at a grade of 5 µm.
Benefits
- Filter regulators for general purpose pneumatic applications
- The design gives high flow with minimum pressure drop
- Non-rising adjusting knob with snap-action lock
- Port size 1/4 NPT
- Outlet pressure adjustable from 0.3 to 10 bar
- Flow 6.5 dm³/s
Applications
The unit sits at the start of the air preparation ahead of valve islands, cylinders and tools.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren B07-205-M1MA |
| Series | B07 |
| Product line | 07 Series |
| Regulator type | General purpose |
| Relieving function | Relieving |
| Adjustment | Knob |
| Adjusting knob | Acetal |
| Port size | 1/4 NPT |
| Gauge port | Rc1/8 |
| Maximum inlet pressure | 17 bar |
| Adjustable outlet pressure | 0.3 to 10 bar |
| Flow | 6.5 dm³/s |
| Filtration grade | 5 µm |
| Filter element | Polypropylene (PP) |
| Drain | Manual |
| Bowl material | Zinc alloy |
| Bowl type | Metal |
| Medium | Compressed air |
| Temperature range | -34 to 65 °C |
| Body material | Zinc alloy |
| Spring bonnet | Acetal |
| Seal material | Nitrile rubber (NBR) |
| Height | 164 mm |
| Width | 38 mm |
| Length | 41 mm |
| Weight | 0.26 kg |
| Country of origin | Mexico |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | B07-205-M1MA |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day. Ask a question
