B07 Series filter/regulator, 1/4 NPT, 5µm, 0.3-10 bar, automatic drain, without gauge - Norgren B07-205-A1MA

Air preparation units combine filtration, pressure regulation and further functions in one device. The B07 Series filter/regulator Norgren B07-205-A1MA accepts an inlet pressure up to 17 bar and is designed for port 1/4 NPT.

Benefits

• Filter regulators for general purpose pneumatic applications
• The design gives high flow with minimum pressure drop
• Non-rising adjusting knob with snap-action lock
• Port size 1/4 NPT
• Outlet pressure adjustable from 0.3 to 10 bar
• Flow 6.5 dm³/s

Applications

The unit sits at the start of the air preparation ahead of valve islands, cylinders and tools.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive.
