for Adapterplatte 1825503244 ISO1-2-END-TYPEF-G3/8-G1/2. Aventics fitting connects compressed-air lines quickly, tightly and pressure-tight for pneumatic installation.
For Adapterplatte 1825503244 ISO1-2-END-TYPEF-G3/8-G1/2 - Aventics Endplatten
AVENTICS Original product
Net price (excl. VAT)
€46.47 €39.05
Item AVE-1825503244
Manufacturer no. 1825503244
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.1825503244
Country of originGermany
Customs tariff number84819000
ConditionNeu
Artikel
AVE-1825503244
Frequently Bought Together
- This Item: €46.47 €39.05
- AS5-ACC-G100 - Aventics R480326132 €1,617.34 €1,359.11
- C12P-032-0080-22101MA11G33-M00-000-0000 - Aventics 7471315380 €309.36 €259.97
Aventics fitting connects compressed-air lines quickly, tightly and pressure-tight for pneumatic installation.
Technical data
| Design | Grundplatte |
| Richtung pneum. Port (1) | Seitlich |
| Richtung pneum. Port (3,5) | Seitlich |
| Entlüftungstyp | Anschlüsse getrennt |
| Entlüftung (3,5) | mit gefasster Entlüftung (3/5) |
| Baugröße | ISO 1, ISO 2 |
| Normen | ISO 5599-1 |
| BetriebsPressure min. | -0.95 bar |
| BetriebsPressure max. | 16 bar |
| UmgebungsTemperature min. | -15 °C |
| UmgebungsTemperature max. | 70 °C |
| MediumsTemperature min. | -15 °C |
| MediumsTemperature max. | 80 °C |
| Medium | Druckluft |
| Befestigungsschraube | Außensechskant |
| Weight | 0.255 kg |
| Material Grundplatte | Aluminium-Druckguss |
| Material Dichtungen | Acrylnitril-Butadien-Kautschuk |
Version
for Adapterplatte 1825503244 ISO1-2-END-TYPEF-G3/8-G1/2.
Manufacturer
Genuine Aventics.
| Hersteller-Nr | 1825503244 |
|---|---|
| Manufacturer | Aventics |
| Country of Manufacture | Germany |
| Weight | 0.260000 |
| Zolltarifnummer | 84819000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Originalprodukt |
| Artikelzustand | Neu |
