Double-acting compact cylinder Ø 63 mm stroke 20 mm ADN-S-63-20-I-P-A - Festo 5132666

The compact cylinder ADN-S-63-20-I-P-A provides 1870 N advance and 1750 N retracting force at 6 bar while its Ø 63 mm piston and 20 mm stroke take up little space. The piston rod with female thread takes the tooling or load, the air port is G1/8. Proximity switches report the end positions of the Ø 63 mm piston to the controller.

Benefits

• Theoretical force at 6 bar: 1870 N advance, 1750 N return
• Elastic end-position cushioning P at both ends, up to 1.3 J impact energy
• Piston rod with female thread made of high-alloy stainless steel
• Position detection via proximity switches
• Operating pressure 0.4 to 10 bar
• LABS (PWIS) conformity to VDMA24364-B2-L

Applications

The short 20 mm stroke makes the cylinder a choice for stoppers, hold-downs and clamping fixtures with little installation space. Installed in any orientation, the ADN-S-63-20-I-P-A runs on compressed air to ISO 8573-1:2010 [7:4:4].
