Double-acting compact cylinder Ø 63 mm stroke 90 mm ADN-63-90-A-P-A-Q-70K8 - Festo 579022

Ø 63 mm piston, 90 mm stroke: the double-acting compact cylinder ADN-63-90-A-P-A-Q-70K8 from the ADN series is the Festo version with part number 579022. The letter A after the cushioning code in type ADN-63-90-A-P-A-Q-70K8 stands for position detection via proximity switches. Being double-acting, the Ø 63 mm piston is driven by compressed air in both directions.

Key benefits

• Piston Ø 63 mm, stroke 90 mm
• Cushioning P: elastic rings at both ends
• Piston rod with male thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 1.3 kg

Typical applications

The ADN-63-90-A-P-A-Q-70K8 handles pushing, lifting and ejecting movements over 90 mm in assembly systems, packaging machines and feeding equipment.
