Double-acting compact cylinder Ø 63 mm stroke 25 mm ADN-63-25-A-P-A-S11 - Festo 579194
The double-acting Festo compact cylinder ADN-63-25-A-P-A-S11 works with a Ø 63 mm piston and a 25 mm stroke and is much shorter than a standard cylinder. Both end positions are cushioned by elastic rings. The load is coupled via the piston rod with male thread.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a 25 mm stroke and a Ø 63 mm piston, the ADN compact cylinder ADN-63-25-A-P-A-S11 covers short linear movements. According to type code ADN-63-25-A-P-A-S11, the cylinder is prepared for end-position sensing with proximity switches. Compressed air drives the piston both ways, so advance and return over 25 mm are powered.
Benefits
- Piston Ø 63 mm, stroke 25 mm
- Cushioning P: elastic rings at both ends
- Piston rod with male thread
- Position detection via proximity switches
- Double-acting: force in both directions
Applications
The short 25 mm stroke makes the cylinder a choice for stoppers, hold-downs and clamping fixtures with little installation space.
Technical data
| Order type | ADN-63-25-A-P-A-S11 |
|---|---|
| Festo part number | 579194 |
| Piston diameter | 63 mm |
| Stroke | 25 mm |
| Mode of operation | double-acting |
| Piston rod end | male thread |
| Cushioning | P: elastic cushioning rings/plates at both ends |
| Position detection | via proximity switch |
| Further type code elements | S11 |
| Customs tariff number | 84123100 |
| Manufacturer | Festo |
| Hersteller-Nr | ADN-63-25-A-P-A-S11 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 63 |
| Stroke [mm] | 25 |
| Function | double-acting |
| Series | ADN |
| Bore (mm) | 63 |
