Double-acting compact cylinder Ø 50 mm stroke 80 mm ADN-50-80-I-PPS-A-"M8"K5 - Festo 609900

The Festo compact cylinder ADN-50-80-I-PPS-A-"M8"K5 moves its load over an 80 mm stroke, the piston measures Ø 50 mm. According to type code ADN-50-80-I-PPS-A-"M8"K5, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 50 mm piston is driven by compressed air in both directions.

Benefits at a glance

• Piston Ø 50 mm, stroke 80 mm
• PPS end-position cushioning without adjustment
• Piston rod with female thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 0.9 kg

Use

The ADN-50-80-I-PPS-A-"M8"K5 handles pushing, lifting and ejecting movements over 80 mm in assembly systems, packaging machines and feeding equipment.
