Double-acting compact cylinder Ø 50 mm stroke 100 mm ADN-50-100-A-PPS-A - Festo 583208

The Festo compact cylinder ADN-50-100-A-PPS-A moves its load over a 100 mm stroke, the piston measures Ø 50 mm. The letter A after the cushioning code in type ADN-50-100-A-PPS-A stands for position detection via proximity switches. Compressed air drives the piston both ways, so advance and return over 100 mm are powered.

Benefits

• Piston Ø 50 mm, stroke 100 mm
• Self-adjusting pneumatic cushioning PPS
• Piston rod with male thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 1 kg

Applications

Typical tasks are ejecting, shifting and positioning workpieces over 100 mm, wherever a standard cylinder would be too long.
