Double-acting compact cylinder Ø 50 mm stroke 10 mm ADN-50-10-I-P-A-"M8"K5 - Festo 594797

Ø 50 mm piston, 10 mm stroke: the double-acting compact cylinder ADN-50-10-I-P-A-"M8"K5 from the ADN series is the Festo version with part number 594797. According to type code ADN-50-10-I-P-A-"M8"K5, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 50 mm piston is driven by compressed air in both directions.

Benefits

• Piston Ø 50 mm, stroke 10 mm
• Elastic end-position cushioning P at both ends
• Piston rod with female thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 0.55 kg

Applications

With a 10 mm stroke, the ADN-50-10-I-P-A-"M8"K5 suits clamping, holding and stopping tasks in fixtures that need only a few millimetres of travel.
