Double-acting compact cylinder Ø 32 mm stroke 320 mm ADN-32-320-A-PPS-A - Festo 578858

With a 320 mm stroke and a Ø 32 mm piston, the ADN compact cylinder ADN-32-320-A-PPS-A covers short linear movements. According to type code ADN-32-320-A-PPS-A, the cylinder is prepared for end-position sensing with proximity switches. Compressed air drives the piston both ways, so advance and return over 320 mm are powered.

Benefits

• Piston Ø 32 mm, stroke 320 mm
• PPS end-position cushioning without adjustment
• Piston rod with male thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 1.2 kg

Applications

The ADN-32-320-A-PPS-A handles pushing, lifting and ejecting movements over 320 mm in assembly systems, packaging machines and feeding equipment.
