Compact cylinder, double-acting, Ø 25 mm stroke 70 mm ADN-25-70-I-PPS-A - Festo 8178886

295 N on advance and 247 N on return at 6 bar: the double-acting Festo ADN-25-70-I-PPS-A moves its 25 mm piston over a 70 mm stroke. The installation dimensions follow ISO 21287.

Benefits

• Self-adjusting end-position cushioning PPS over a 3.5 mm cushioning length, adapts to load and speed without manual adjustment
• Theoretical force at 6 bar: 295 N advance, 247 N return
• Dimensions to ISO 21287, so standard mounting accessories fit directly
• Cleanroom-suitable, class 5 to ISO 14644-1, PWIS (LABS) conformity VDMA24364-B1/B2-L
• Operating pressure 1.5 to 10 bar, ambient temperature -20 to 80 °C
• Mounting via through-holes or female thread in the cover, port M5

Applications

The ADN-25-70-I-PPS-A suits clamping, ejecting and short positioning moves of up to 70 mm in fixtures and handling modules. With port M5 and piston rod thread M6 it connects without adapters.
