Double-acting compact cylinder Ø 25 mm stroke 40 mm ADN-25-40-I-P-A-"M5"K5 - Festo 610284

With a 40 mm stroke and a Ø 25 mm piston, the ADN compact cylinder ADN-25-40-I-P-A-"M5"K5 covers short linear movements. The letter A after the cushioning code in type ADN-25-40-I-P-A-"M5"K5 stands for position detection via proximity switches. Being double-acting, the Ø 25 mm piston is driven by compressed air in both directions.

Benefits at a glance

• Piston Ø 25 mm, stroke 40 mm
• Elastic end-position cushioning P at both ends
• Piston rod with female thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 0.25 kg

Use

Typical tasks are ejecting, shifting and positioning workpieces over 40 mm, wherever a standard cylinder would be too long.
