Double-acting compact cylinder Ø 100 mm stroke 133 mm ADN-100-133-A-P-A-R3 - Festo 593632

Ø 100 mm piston, 133 mm stroke: the double-acting compact cylinder ADN-100-133-A-P-A-R3 from the ADN series is the Festo version with part number 593632. According to type code ADN-100-133-A-P-A-R3, the cylinder is prepared for end-position sensing with proximity switches. Compressed air drives the piston both ways, so advance and return over 133 mm are powered.

Benefits

• Piston Ø 100 mm, stroke 133 mm
• Cushioning P: elastic rings at both ends
• Piston rod with male thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 3.4 kg

Applications

The ADN-100-133-A-P-A-R3 handles pushing, lifting and ejecting movements over 133 mm in assembly systems, packaging machines and feeding equipment.
