Double-acting compact cylinder Ø 100 mm stroke 100 mm ADN-100-100-A-P-A-EX4 - Festo 579048

With a 100 mm stroke and a Ø 100 mm piston, the ADN compact cylinder ADN-100-100-A-P-A-EX4 covers short linear movements. The letter A after the cushioning code in type ADN-100-100-A-P-A-EX4 stands for position detection via proximity switches. Compressed air drives the piston both ways, so advance and return over 100 mm are powered.

Benefits

• Piston Ø 100 mm, stroke 100 mm
• Elastic end-position cushioning P at both ends
• Piston rod with male thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 2.7 kg

Applications

The ADN-100-100-A-P-A-EX4 handles pushing, lifting and ejecting movements over 100 mm in assembly systems, packaging machines and feeding equipment.
