5/2-way mushroom-button valve, red, G 1/4, 980 l/min, Ø 30.5 mm panel hole - YPC PMEV410

Red is the customary colour for stop and off functions. The mushroom head of this 5/2-way valve offers a large contact surface that is easy to hit, even with a gloved hand or the palm. It installs in a Ø 30.5 mm panel hole and switches up to 980 l/min through G 1/4 ports.

Advantages

• Weighs just 195 g, built from die-cast aluminium body and cover, aluminium spool, NBR seals, carbon steel plunger.
• Effective area of 19.0 mm² for 980 l/min, enough for small cylinders or as a pilot signal to a larger valve.
• Runs without a lubricator on filtered compressed air, lubricated or not, and on inert gases from 0 to 8 bar.
• Two G 1/4 working ports and two separate G 1/8 exhaust ports, so the valve drives a double-acting cylinder in both directions.
• Fits a Ø 30.5 mm panel hole, next to electrical control devices of the same size.

Applications

• Workstations where operators wear gloves
• Start or stop commands given with the palm of the hand
• Direct control of a double-acting cylinder from the panel
