This three-piece stainless steel ball valve shuts off the flow in the line with a quarter turn. This version carries mounting flange to ISO 5211 F04 at pressure rating PN 0 - 63 bar.
Three-piece stainless steel ball valve, Schweißende 42.4, pressure rating PN 0 - 63 bar
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€159.78
Item
FL-353308
Manufacturer no.
KH 1143 AS ES E
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.KH 1143 AS ES E
EAN4050571843663
Customs tariff number84818081
ConditionNew
Artikel
FL-353308
Frequently Bought Together
-
This Item:
€159.78
-
Angle seat valve, pneumatic, G 1-1/4", brass, normally open, standard
€375.62
-
PVC-U ball valve, electric actuator, DN 25, solvent socket, FKM, battery return, 24-240 V
€1,597.87
Total price
The three-piece stainless steel ball valve version shuts off the flow in the line with a quarter turn. Key figures are mounting flange to ISO 5211 F04 together with pressure rating PN 0 - 63 bar. The stated material is stainless steel 1.4408. Sealing is handled by PTFE.
Benefits
- full bore in the open position and therefore low pressure loss, verified by mounting flange to ISO 5211 F04
- material stainless steel 1.4408 as stated in the data
- sealing material PTFE
- temperature range -20 to +200 °C
- made to DIN 3202
- made to EN 12982
Technical data
| dimension A [mm] | 42.4 |
|---|---|
| nominal size DN [mm] | 32 |
| dimension L [mm] | 110 |
| pressure rating PN [bar] | 0 - 63 |
| dimension B [mm] | 35.1 |
| dimension H [mm] | 85 |
| dimension R [mm] | 147 |
| mounting flange to ISO 5211 | F04 |
| material | stainless steel 1.4408 |
| sealing material | PTFE |
| temperature range | -20 to +200 °C |
| media | water, oil, compressed air, fuels, solvents, aggressive media |
Applications
Its place is in pipework, compressed air networks and plant construction. The media specification covers water, oil, compressed air, fuels, solvents, aggressive media.
Standards and conformity
The design is based on DIN 3202 and EN 12982.
| Weight | 1.700000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | KH 1143 AS ES E |
| EAN | 4050571843663 |
| Zolltarifnummer | 84818081 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN 3202, DIN EN 12982, ISO 5211 |
