3/2-way solenoid valve, spring return (NC), G 1/8", 230 V AC, 500 l/min, nominal size 3.9 mm, 3 VA
With 500 l/min at connection G 1/8" this 3/2-way solenoid valve moves larger cylinders without noticeable throttling. The switching function is spring return (NC). The materials are body and spool aluminium, seals NBR, pilot polyamide.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
This 3/2-way solenoid valve switches the air path electrically and needs no manual action at the machine. The connection is G 1/8" and control is by 230 V AC. The switching function is spring return (NC). The operating pressure is stated as 1.5 to 8 bar. The materials are body and spool aluminium, seals NBR, pilot polyamide.
Advantages
- Temperature range of -5 to +60 °C, which covers use in the machine room as well as outdoors.
- Service life min. 40 million switching cycles, enough for continuous multi-shift operation.
- Connection G 1/8" and exhaust G 1/8", so the piping follows the existing line network.
- Control voltage tolerance plus/minus 10 percent, which makes short supply dips uncritical.
- Media oiled and non-oiled, filtered compressed air, so no separate treatment is needed.
Applications
- Plants operated within the temperature range -5 to +60 °C.
- Replacement of a defective valve of the same type in existing machines.
- Control of double-acting cylinders with an air demand up to 500 l/min.
- Sequencing of pneumatic axes with connection G 1/8" in handling equipment.
Technical data
| Feature | Value |
|---|---|
| Function | spring return (NC) |
| Control voltage | 230 V AC |
| Thread G1 (2x) | G 1/8" |
| Exhaust thread G1 (1x) | G 1/8" |
| Nominal diameter [mm] | 3.9 |
| Flow rate [l/min] | 500 |
| Power consumption (AC) [VA] | 3 |
| Dimensions [mm] | A 92.1, B 27, C 18, D 7.5, E 15.5, F 21, H1 3.2, H2 3.3, J 13, K 16.5, L 19, M 18.0, N 16, O 27.0, P 1.5, U 55.2, V 33.9, W 2 |
| Material body and spool | aluminium |
| Material seals | NBR |
| Material pilot | polyamide |
| Temperature range | -5 to +60 °C |
| Operating pressure | 1.5 to 8 bar |
| Media | oiled and non-oiled, filtered compressed air |
| Switching time (at 5 bar) | below 50 ms, max. 5 switching cycles / sec. (5/3-way: max. 3 switching cycles / sec.) |
| Control voltages | Standard: 24 V DC, 230 V AC, other voltages on request |
| Voltage tolerance | plus/minus 10 percent |
| Protection class | IP 65 |
| Service life | min. 40 million switching cycles |
| Weight | 0.115 kg |
| Manufacturer | E.MC |
| Hersteller-Nr | RV 3211-06-230V |
| EAN | 4050571714628 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Leistungsaufnahme (AC) [VA] | 3 |
