3/2-way shut-off and exhaust valve, electrically piloted, G 1/4, 24 V AC, IP 65 - E.MC
Electrically piloted 3/2-way shut-off valve G 1/4 for 24 V AC: closes the supply and vents the downstream line. Working pressure 2 to 10 bar, IP 65, mounting bracket included.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
This G 1/4 shut-off valve cuts the compressed air supply to a machine on an electrical signal and at the same time vents the downstream line through its own G 1/4 exhaust port. The 24 V AC coil works on the control transformers found in older installations, and the working pressure range is 2 to 10 bar.
Advantages
- Electrically piloted 3/2-way function: shut off the supply and vent the downstream line in one unit
- Valve body and pilot seat in aluminium alloy, NBR seals
- Full-size G 1/4 exhaust port so the system depressurises quickly
- IP 65 protection, voltage tolerance ±10 %
Applications
- Central shut-off and venting of compressed air from the machine control
- Depressurising plant sections before tool changes and maintenance
- Installation downstream of filter regulators of the same size
Accessories and spare parts
- Coupling kit for joining filters, regulators and lubricators of the same size
- G 1/4 exhaust silencer for the exhaust port, not included
- Replacement solenoid coil, 24 V AC, connector size 1
Technical data
| Property | Value |
|---|---|
| Design | 3/2-way shut-off and exhaust valve, electrically piloted |
| Series | EAS (E.MC) |
| Port | G 1/4 |
| Exhaust port | G 1/4 |
| Control voltage | 24 V AC |
| Voltage tolerance | ±10 % |
| Solenoid coil | Connector size 1, coil and plug supplied loose |
| Protection class | IP 65 |
| Medium | Clean compressed air, filtered to 40 µm |
| Working pressure | 2 to 10 bar |
| Proof pressure | 15 bar |
| Temperature | -5 to 60 °C, frost-free |
| Materials | Valve body and pilot seat aluminium alloy, NBR seals, stainless steel screws |
| Weight | 330 g |
| Scope of delivery | Valve with mounting bracket, without exhaust silencer |
| Dimension drawing | in the E.MC datasheet (PDF) |
| Manufacturer | E.MC |
| Hersteller-Nr | EAS 2100-02-24VAC |
| EAN | 4050571981617 |
| Zolltarifnummer | 84811005 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
