3/2-way solenoid valve, direct-acting, stainless steel 1.4401, G 1/4, DN 3, 0 to 8 bar, FKM, 24 V DC, analysis version - Riegler 185512

For 0 to 8 bar and G 1/4: the Riegler 3/2-way solenoid valve for any flow direction in direct-acting design. Stainless steel 1.4401 body, FKM seals, coil 24 V DC. Medium temperature 0 to 90 °C. Media-separated for critical media.

Benefits

• Operating pressure 0 to 8 bar at DN 3
• Stainless steel 1.4401 body, valve seat stainless steel, FKM seals
• Medium temperature 0 to 90 °C, ambient 0 to 55 °C
• Manual override for testing without power
• Coil voltage 24 V DC, pin terminal to DIN EN 175301-803, type A, degree of protection IP 65
• Coil system separated from the medium by a diaphragm, suitable for aggressive acids and alkalis

Applications

• Switching critical media such as aggressive acids and alkalis
• As a distributing or mixing valve in 3/2-way design
