20AG Series high flow pressure regulator, G1/2, 0.2-8 bar, without gauge - Norgren 20AG-X4G-PH103
Regulation stays even when demand changes. The 20AG Series high flow pressure regulator Norgren 20AG-X4G-PH103 covers the temperature range -20 to 80 °C and seals with synthetic rubber.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pressure regulators keep the working pressure constant even when the line pressure varies. The 20AG Series high flow pressure regulator Norgren 20AG-X4G-PH103 covers the temperature range -20 to 80 °C and is designed for port G1/2.
Benefits
- Ported pressure regulators for general purpose and high flow applications
- The large diaphragm responds quickly to changing demand and line pressure
- The balanced valve keeps inlet pressure variations away from the outlet
- Port size G1/2
- Outlet pressure adjustable from 0.2 to 8 bar
- Flow 60 dm³/s
Applications
The regulator sits ahead of cylinders, tools and valve islands that need a fixed working pressure.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 20AG-X4G-PH103 |
| Series | 20AG |
| Regulator type | General purpose |
| Relieving function | Relieving |
| Adjustment | Knob |
| Adjusting knob | Plastic |
| Port size | G1/2 |
| Gauge port | Rc1/8 |
| Maximum inlet pressure | 28 bar |
| Adjustable outlet pressure | 0.2 to 8 bar |
| Flow | 60 dm³/s |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Body material | Zinc alloy |
| Spring bonnet | Aluminium alloy |
| Seal material | Synthetic rubber |
| Height | 187 mm |
| Width | 86 mm |
| Length | 99 mm |
| Weight | 1.4 kg |
| Country of origin | Mexico |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 20AG-X4G-PH103 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
