20AG Series high flow pressure regulator, G1, 0.2-8 bar, without gauge - Norgren 20AG-8G-PH100
Regulation stays even when demand changes. The 20AG Series high flow pressure regulator Norgren 20AG-8G-PH100 regulates the outlet pressure in the range 0.2 to 8 bar and covers the temperature range -20 to 80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pressure regulators keep the working pressure constant even when the line pressure varies. The 20AG Series high flow pressure regulator Norgren 20AG-8G-PH100 seals with synthetic rubber and covers the temperature range -20 to 80 °C.
Benefits
- Ported pressure regulators for general purpose and high flow applications
- The large diaphragm responds quickly to changing demand and line pressure
- The balanced valve keeps inlet pressure variations away from the outlet
- Port size G1
- Outlet pressure adjustable from 0.2 to 8 bar
- Flow 100 dm³/s
Applications
Typical installations are production lines, test benches and machines with several pressure levels.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 20AG-8G-PH100 |
| Series | 20AG |
| Regulator type | General purpose |
| Relieving function | Non-relieving |
| Adjustment | T-bar |
| Adjusting knob | Zinc plated steel |
| Port size | G1 |
| Gauge port | Rc1/8 |
| Maximum inlet pressure | 28 bar |
| Adjustable outlet pressure | 0.2 to 8 bar |
| Flow | 100 dm³/s |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Body material | Zinc alloy |
| Spring bonnet | Aluminium alloy |
| Seal material | Synthetic rubber |
| Height | 232 mm |
| Width | 124 mm |
| Length | 124 mm |
| Weight | 2.9 kg |
| Country of origin | Mexico |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | 20AG-8G-PH100 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
