2/2-way solenoid valve, de-energised closed (NC), G 1/2", 115 V AC, 0 to 16 bar, Kv 65 l/min, 26 VA

This 2/2-way solenoid valve controls the air path in a compressed air system. The switching function is de-energised closed (NC). The connection is G 1/2". The operating pressure is stated as 0 to 16 bar. The materials are body 1.4581 (internal parts 1.4104), seal FKM.

Advantages

• Media Compressed air, neutral gases, water, neutral low-viscosity media, other media on request, so no separate treatment is needed.
• Kv value of 65 l/min, from which the flow rate for the actual pressure drop can be calculated.
• Mounting position with upright solenoid, de-energised open (NO) also with horizontal solenoid, which has to be observed before installation.
• Switching function de-energised closed (NC), so the rest position is clearly defined.
• Control with 115 V AC at a power consumption of 26 VA, which relieves the supply when many valves share one cabinet.

Applications

• Plants operated within the temperature range 0 to +80 °C.
• Replacement of a defective valve of the same type in existing machines.
• Sequencing of pneumatic axes with connection G 1/2" in handling equipment.
• Installation in control cabinets with a supply of 115 V AC.
