18D Electro-mechanical hydraulic pressure switch, flange, 5-70 bar - Norgren 0883100000000000
The design withstands rough ambient conditions. The 18D Electro-mechanical hydraulic pressure switch Norgren 0883100000000000 reaches protection class IP65 and weighs 0.2 kg.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pressure switches report when a set pressure is exceeded or undercut. The 18D Electro-mechanical hydraulic pressure switch Norgren 0883100000000000 is suitable for gases, liquids and is designed for port Flange.
Benefits
- Gold-plated contacts
- High cycle life
- Vibration resistant to 15 g
- Port size Flange
- Temperature range -25 to 80 °C
- Body made of Aluminium, Steel
Applications
Typical installations are compressor stations, machine tools and test benches.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 10,000,000 cycles.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 0883100000000000 |
| Series | 18D Hydraulic |
| Product line | 18D |
| Port size | Flange |
| Pressure range | 5 to 70 bar |
| Type of pressure | Relative pressure |
| Medium | Gases, Liquids |
| Temperature range | -25 to 80 °C |
| Body material | Aluminium, Steel |
| Seal material | Polytetrafluoroethylene (PTFE), Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A |
| Protection class | IP65 |
| b10 value | 10,000,000 cycles |
| Height | 30 mm |
| Width | 30 mm |
| Length | 76 mm |
| Weight | 0.2 kg |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Weight | 0.230000 |
| Manufacturer | Norgren |
| Hersteller-Nr | 0883100000000000 |
| Zolltarifnummer | 90322000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
| Certification | DIN EN ISO 13849 |
