140 failsafe series current to pressure electronic converter, 1/4 NPT, 0.2-1 bar - Norgren EX14001BK4EE1
The parameters are set at the device or over the interface. The 140 failsafe series current to pressure electronic converter Norgren EX14001BK4EE1 is manufactured in Czechia and reaches protection class IP66, NEMA 4X.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Proportional valves and converters turn an electrical signal into pressure or flow without steps. The 140 failsafe series current to pressure electronic converter Norgren EX14001BK4EE1 is manufactured in Czechia and reaches protection class IP66, NEMA 4X.
Benefits
- Explosion proof, intrinsically safe and type nA nL
- Field replaceable filter
- On signal failure the pressure drops to zero
- Port size 1/4 NPT
- Outlet pressure adjustable from 0.2 to 1 bar
- Flow 300 l/min
Applications
Typical installations are test benches, coating plants and machine tools.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP66, NEMA 4X.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren EX14001BK4EE1 |
| Series | 140 Failsafe |
| Product line | Watson Smith |
| Valve function | 3/2 |
| Function | NC |
| Valve technology | Diaphragm |
| Mounting | Bracket |
| Port size | 1/4 NPT |
| Maximum inlet pressure | 10.3 bar |
| Adjustable outlet pressure | 0.2 to 1 bar |
| Flow | 300 l/min |
| Medium | Compressed air |
| Temperature range | -40 to 85 °C |
| Body material | Aluminium, Zinc |
| Electrical connection | 1/2 NPT |
| Operating voltage | 6.5 V DC |
| Control signal | 4 to 20 mA |
| Protection class | IP66, NEMA 4X |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Weight | 2.2 kg |
| Manufacturer | Norgren |
| Hersteller-Nr | EX14001BK4EE1 |
| Zolltarifnummer | 90328100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
