Ready assembled to 0.3 m and therefore installable without crimping tools. Type EN 853 1 SN carries DN 19 at 40 bar and connects with M 30x2.
Compressed air hose assembly EN 853 1 SN, DN 19, M 30x2, pipe connection 22 L, DKO / DKO, 0.3 m
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€76.39
Item
FL-309244
Manufacturer no.
2SN19-22L-300-G
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.2SN19-22L-300-G
EAN4050571191177
Customs tariff number40092200
ConditionNew
Artikel
FL-309244
Frequently Bought Together
Type 1 SN to EN 853 joins two connection points over 0.3 m at DN 19 and 40 bar working pressure. Thread M 30x2 and pipe connection 22 L define the mating point. The reinforcement consists of one steel wire braid. Both ends carry the same connection form, so the assembly can be fitted either way round.
Benefits
- working pressure 40 bar at nominal size DN 19
- reinforcement of one steel wire braid to EN 853 1 SN
- temperature range -40 to +100 °C (briefly +120 °C)
- cut to 0.3 m and crimped at both ends, no assembly work of your own is needed
- cover resistant to ozone and weathering
- connecting thread M 30x2 for the pipe connection 22 L, DKO / DKO
Technical data
| hose type | EN 853 1 SN |
|---|---|
| version | for compressed air |
| nominal size DN [mm] | 19 |
| working pressure [bar] | 40 |
| length [m] | 0.3 |
| end connections | DKO / DKO |
| pipe connection | 22 L |
| thread d/D | M 30x2 |
| inner tube | synthetic rubber |
| cover | synthetic rubber, resistant to ozone and weathering |
| reinforcement | one steel wire braid |
| temperature range | -40 to +100 °C (briefly +120 °C) |
| media | compressed air |
| field of use | compressed air applications up to 40 bar |
Applications
It is used in maintenance as a replacement for damaged lines of the same nominal size. According to the data sheet compressed air is approved.
Standards and conformity
The hose is built to EN 853 as type 1 SN and reinforced with one steel wire braid.
| Weight | 0.650000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | 2SN19-22L-300-G |
| EAN | 4050571191177 |
| Zolltarifnummer | 40092200 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | für Druckluft |
| Length [mm] | 300 |
| Norm | DIN EN 853 |
