3/2-way push button valve, red, M 5, 80 l/min, 0 to 12 bar, body anodised aluminium

Wherever compressed air has to be redirected quickly and repeatably, this 3/2-way push button valve sits between the service unit and the actuator. The connection M 5 provides 80 l/min. The operating pressure is stated as 0 to 12 bar. The materials are body anodised aluminium, internal parts Aluminium, brass and stainless steel, seals NBR.

Advantages

• Materials body anodised aluminium, internal parts Aluminium, brass and stainless steel, seals NBR, matched to the intended service.
• Temperature range of -10 to +70 °C, which covers use in the machine room as well as outdoors.
• Media oiled and non-oiled, filtered compressed air, so no separate treatment is needed.
• Actuation by Push button, which fixes the direction of response.
• Actuating force of 13 N, so a light ramp is enough to trip the valve.

Applications

• Cycled feeding and clamping units in fixture building.
• Plants operated within the temperature range -10 to +70 °C.
• Replacement of a defective valve of the same type in existing machines.
• Control of double-acting cylinders with an air demand up to 80 l/min.
