Keeps the working pressure constant even when the line pressure fluctuates. The pressure setting range extends over 0.5 - 10 bar. The device is screwed in with G 1/8".
Pressure regulator, G 1/8", 0.5 - 10 bar, zinc die casting Z410, temperature range -10 to +60 °C
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€42.52
Item
FL-002912
Manufacturer no.
DR 00
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.DR 00
EAN4050571264482
Customs tariff number84811099
ConditionNew
Artikel
FL-002912
Frequently Bought Together
-
This Item:
€42.52
-
Safety valve, TÜV type-tested, factory-set, G 1/2", DN 8, 11.00 bar, nickel-plated brass
€45.43
-
Safety relief valve G 1-1/2", factory set and sealed, DN 31, 18 bar, brass
€311.18
Total price
Anyone who wants to supply a machine with a constant pressure sets it on this pressure regulator. The material used is zinc die casting Z410. The pressure setting range covers 0.5 - 10 bar. The connection is made via thread G 1/8". The temperature range extends over -10 to +60 °C.
Benefits
- Temperature range -10 to +60 °C for use in the workshop and in the plant
- Version according to Richtlinie 2014/34/EU
- Material zinc die casting Z410 determines strength and resistance of the part
- Released for compressed air, neutral gases
- Pressure setting range 0.5 - 10 bar as the leading rating of the device
- Connection thread G 1/8" for direct installation in the line
Technical data
| Property | Value |
|---|---|
| Thread | G 1/8" |
| Pressure setting range [bar] | 0.5 - 10 |
| Gauge indication [bar] | 0 - 16 |
| Mounting bracket | available as an accessory |
| Body material | zinc die casting Z410 |
| Temperature range | -10 to +60 °C |
| Media | compressed air, neutral gases |
| Scope of delivery | pressure regulator including 40 mm pressure gauge |
| Standards | Richtlinie 2014/34/EU |
Applications
Assembly lines and manual workstations, pneumatic drives, painting and cleaning technology, laboratory supply.
Standards and conformity
The data sheets refer to Richtlinie 2014/34/EU. Further approvals are not documented and are therefore not stated.
| Weight | 0.290000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | DR 00 |
| EAN | 4050571264482 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/8 |
| Druckregelbereich [bar] | 0,5 - 10 |
| Manometeranzeige [bar] | 0 - 16 |
| Befestigungswinkel | WHM 30 |
