Mechanically actuated 3/2-way valve (NC) built as a limit switch with cam actuation and roller plunger, port G 1/8". Anodized aluminium body, up to 12 bar. For position and end-position sensing in pneumatic controls.
3/2-Way Limit Switch with Cam, G 1/8", NC - Airtec E 28 310
AIRTEC
Original product
Net price (excl. VAT)
€26.42
€22.20
Item
FL-E-28-310
Manufacturer no.
E 28 310
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.E 28 310
EAN4050571277796
Customs tariff number84812090
ConditionNew
Artikel
FL-E-28-310
The Airtec E 28 310 is a mechanically actuated 3/2-way valve, normally closed (NC), built as a limit switch with cam actuation via lever, roller plunger and cam. It signals end positions in pneumatic control systems and switches compressed air up to 12 bar at the G 1/8" port.
Benefits
- Mechanical cam actuation with roller plunger for reliable end-position sensing without electrics.
- Anodized aluminium body for corrosion protection and low weight of 0.050 kg.
- Operating pressure 0 to 12 bar covers common pneumatic control circuits.
- G 1/8" port for higher flow than the M 5 version.
- Runs on lubricated and non-lubricated compressed air for flexible use in existing systems.
Technical data
| Function | 3/2-way, normally closed (NC) |
| Actuation | mechanical, limit switch with cam, lever and roller plunger |
| Port | G 1/8" |
| Body | anodized aluminium |
| Internal parts | brass, stainless steel and aluminium |
| Seals | NBR |
| Lever | aluminium |
| Plunger and roller | steel and plastic |
| Temperature range | -10 °C to +70 °C |
| Operating pressure | 0 to 12 bar |
| Media | lubricated and non-lubricated, filtered compressed air |
| Pressure inlet | NC/NO type at any port |
| Weight | 0.050 kg |
Applications
End-position and position sensing on cylinders, workpiece fixtures and feed units, plus mechanical triggering of control functions in machine and fixture building.
| Hersteller-Nr | E 28 310 |
|---|---|
| Manufacturer | Airtec |
| EAN | 4050571277796 |
| Weight | 0.050000 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
