HydraMax Bolt Tensioner, M64-M76 thread - Enerpac HM13LC

The HydraMax HM13LC bolt tensioner hydraulically preloads bolted joints in the M64-M76 thread range at up to 1500 bar, delivering high and repeatable bolt loads. Its long 15 mm stroke with built-in over-stroke protection covers even large elongation travels reliably.

Benefits

• Twin ports for quick connection and linking of multiple tools
• Working pressure up to 1500 bar for high bolt loads in a compact envelope
• 15 mm stroke with relief valve for over-stroke prevention and spring return
• Quick-release bridge and stroke indicator for controlled operation
• Captive socket lowers the risk of falling objects
• Interchangeable adapter kits and anti-slip grip for safe handling

Technical data

• Thread range: M64-M76
• Working pressure: max. 1500 bar
• Stroke: 15 mm
• Action: hydraulic, spring return
• Series: HM (HydraMax)
• Weight: 17.6 kg

Applications

For controlled preloading of flanged joints, for example in plant, power generation and wind energy construction. The tool operates at high pressure and must be used only with the fittings and hoses approved for it.
