4008 kN Capacity, 200 mm Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder - Enerpac HCL4008
Datasheet (PDF)
Pictures are for reference and may not be accurate, actual product may differ
HCL4008, 4008 kN Capacity, 200 mm Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder

4008 kN Capacity, 200 mm Stroke, Single-Acting, High Tonnage, Lock Nut Hydraulic Cylinder - Enerpac HCL4008

ENERPAC Original product
Net price (excl. VAT)
€0.00 €0.00
excl. Shipping Cost
Available Fast shipping
Item ENP-HCL4008
Manufacturer no. HCL4008
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.HCL4008
Country of originUnited States
ConditionNeu
Add to Wish List Add to Compare
Artikel
ENP-HCL4008
Model: HCL4008 |ECCN: EAR99 | Harmonization: 8412210075
Series: HCL |Product Line: Industrial Tools

  • Lock nut provides positive and safe mechanical load holding
  • Low friction locking rings spin easy, save time and effort
  • Designed to withstand 10% side-load up to 90% of maximum stroke
  • Hardened surface resists side-loading and cyclic wear
  • Overflow port as stroke limiter to prevent plunger blow-out
  • Weather protected, inside and out
  • Replaceable bearings enclose the plunger for support throughout the stroke
  • Certified lifting eyes and base mounting holes

Dimension imperial

Collapsed Height A (in)
18.39
Collapsed Height With Optional Tilt Saddle A1 (in)
20.28
Optional Tilt Saddle Addition To Collapsed Height A1 (in)
1.89
Optional Tilt Saddle Diameter J1 (in)
8.27
Extended Height B (in)
26.26
Outside Diameter D (in)
13.78
Cylinder Bore Diameter E (in)
10.63
Base to Advance Port H (in)
2.64
Saddle Diameter J1 (in)
6.26
Saddle Protrusion from Plunger K (in)
0.2
Saddle Maximum Tilt Angle Radius (degrees)
5
Lock Nut Height S (in)
2.56
Base Mounting Holes Thread V
M16 x 2

Dimension metric

Collapsed Height A (mm)
467
Collapsed Height With Optional Tilt Saddle A1 (mm)
515
Optional Tilt Saddle Addition To Collapsed Height A1 (mm)
48
Extended Height B (mm)
667
Outside Diameter D (mm)
350
Cylinder Bore Diameter E (mm)
270
Plunger Diameter F (mm)
Tr 270 x 6
Base to Advance Port H (mm)
67
Saddle Diameter J (mm)
159
Saddle Protrusion from Plunger K1 (mm)
5
Saddle Maximum Tilt Angle Radius (degrees)
5
Lock Nut Height S (mm)
65
Base Mounting Holes Bolt Circle U (mm)
300
Base Mounting Holes Thread V
M16 x 2
Base Mounting Holes Thread Depth Z (mm)
25
More Information
Hersteller-Nr HCL4008
Manufacturer Enerpac
Country of Manufacture United States
Weight 349.000000
Hinweis Industriewerkzeuge
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Originalprodukt
Artikelzustand Neu
