Pump-per-Point Synchronous Lifting System, 3 kW, 460 V - Enerpac EVOP12140J

The EVOP-series pump-per-point synchronous lifting system drives each lifting point with its own pump, reaching up to 8 times the lifting speed of conventional multi-point systems at 700 bar. Variable speed motor control keeps the cylinders within 1 mm of each other.

Benefits

• One pump per lifting point for high flow with high accuracy
• Up to 8x the lifting speed of conventional multi-point systems
• Accuracy down to 1 mm between cylinders via variable frequency drive (VFD)
• Stroke synchronization for level lifting regardless of load distribution
• Ideal for high-tonnage cylinders from 300 to 1000 t capacity

Technical data

• Type: pump-per-point synchronous lifting system
• Drive power: 3 kW
• Operating voltage: 460 V
• Operating pressure: 700 bar
• Weight: 310 kg
• Series: EVOP

Applications

For fast, precise heavy-load lifts with long-stroke cylinders and repetitive operations such as stage-lift systems.
