8-point synchronous lifting system, 7.5 kW, 460 V - Enerpac EVO840460

The EVO-series 8-point synchronous lifting system controls 8 lifting points at once and keeps the cylinders within 1 mm of each other through variable frequency motor control. The integrated 700 bar hydraulic power unit with a 250 l reservoir feeds single- or double-acting cylinders of equal or different capacity.

Benefits

• Synchronized lifting of 8 points with an accuracy of up to 1 mm
• PLC-controlled with an intuitive interface for set-up and operation
• Variable frequency drive motor (VFDM) for precise synchronization and flow control
• Connects single- or double-acting cylinders of the same or different capacity
• Wireless networking of up to 4 power units with a separate master control
• Nine work modes and data recording for documented lifting operations

Technical data

• Lifting points: 8
• Drive power: 7.5 kW
• Operating voltage: 460 V
• Operating pressure: 700 bar
• Reservoir: 250 l
• Motor control: variable frequency drive (VFDM) with PLC
• Series: EVO

Applications

Suitable for driving interlinked hydraulic cylinders, push and pull cylinders, stage-lift jacks and hollow-plunger or lock-nut cylinders when raising heavy loads evenly.
