EMC EMQ 50 A. Compact swivel table, size 50, with fixed stop

Materials:
Body and swivel table anodized aluminum, Piston: Stainless steel with magnet insert, Pinion: Steel, Seals: NBR

Temperature range:
0 to +60 °C

Operating pressure:
max. 10 bar (size 7: max. 7 bar), with shock absorbers: max. 6 bar

Swivel angle:
adjustable 0° - 190°

Version:
With Magnetic piston

Cylinder switch type:
D

Advantages:
•Positioning hole on swivel table, body top and body at bottom for repeatable workpiece mounting,
•Internal table diameter and external table diameter as well as bottom hole suitable for precise alignment of the swivel axis,
•Simple fitting from below and above,
•Hollow shaft for media supply to devices mounted on the swivel table,
•Air connection either from the front or laterally (closed with sealing plugs),
•Main dimensions identical to SMC series MSQ / EMSQ

Version	with fixed stop
size	50
optimum swing time for 90° [s]	0,2 - 1,0
Operating pressure [bar]	max. 10
G (compressed air port)	G 1/8"
optional compressed air port (closed)	M 5
Repair sets	EMQ 50 REP
Spare shock absorber (1 count)	EMQ 50 SD
AA [mm]	82,4
A [mm]	80
AV [mm]	38,0
AW [mm]	22,0
AY [mm]	6
BA	15,5
BB [mm]	63,0
BC [mm]	37,5
BD [mm]	100
BE [mm]	50
CA [mm]	10,0
CB [mm]	37,5
D (h9) [mm]	75
DD (h9) [mm]	77
DE (H9)	35
DF [mm]	11
DG (H9)	26
FA [mm]	11,8
FB [mm]	5,5
FC [mm]	3,5
FD [mm]	7,5
H [mm]	20
J [mm]	10,3
JA [mm]	18
JB	10,5
JC	M 12
JC1 [mm]	18
JJ	M 8
JU	M 14x1.5 (FT)
Q [mm]	46
S [mm]	152
SD [mm]	14,5
SE [mm]	15
SF [mm]	75
SU [mm]	31,3
UU [mm]	66
WA [mm]	26,5
WB [mm]	5H9 (5.5 deep)
WD	M 8
WD1 [mm]	12
WF	55
XA	45
YA [mm]	33
