Electric Hydraulic Pump, Pro, 3/2 Manual Valve, 4 L, 230 V - Enerpac ZU4704LE

The ZU4704LE electric hydraulic pump drives Enerpac cylinders and hydraulic tools at 700 bar operating pressure. Its two-stage Z-class pump element delivers high oil flow at high bypass pressure for short cycle times. The manual valve allows direct control at the unit.

Benefits

• Two-stage Z-class pump element with high oil flow and high bypass pressure for short cycle times
• Up to 18% lower current draw and cooler running than comparable pumps
• Powerful 1.25 kW universal motor with a high power-to-weight ratio and strong low-voltage behaviour
• User-adjustable relief valve built into the valve, 3/8" NPTF oil port
• Sturdy steel reservoir with sight glass and 40-micron breather filter with splash guard
• Sturdy composite shroud protects motor and electronics and forms an ergonomic, non-conductive carry handle

Technical data

• Valve: manual valve
• Reservoir: 4 L
• Motor: 1.25 kW universal motor
• Voltage: 230 V
• Operating pressure: 700 bar
• Weight: 27 kg
• Series: ZU

Applications

For hand-controlled operation of cylinders and hydraulic tools.
