Electric Hydraulic Pump, 3 L, NEMA 6-15 Plug - Enerpac EP3304SI-G

The E-Pulse electric pump powers cylinders and tools up to 700 bar and holds constant output across the full pressure range thanks to smart motor control. The integrated gauge allows pressure to be monitored directly at the unit.

Benefits

• Two-stage pump with high by-pass pressure: 2.13 l/min at 175 bar, 0.52 l/min at 700 bar
• Smart controls keep motor power constant across the pressure range
• 24 VDC power regulator reduces the effect of a poor power supply
• Six-piston block design for even flow and smooth running
• Adjustable speed control via dial for precise operation
• Integrated gauge, pendant control and cord management system

Technical data

• Series: E-Pulse
• Reservoir: 3 L
• Usable oil volume: 1-4 L
• Flow: 2.13 l/min at 175 bar, 0.52 l/min at 700 bar
• Operating pressure: 700 bar
• Connection: NEMA 6-15 plug
• Protection: IP54 (pump), IP67 (pendant)
• Weight: 18.7 kg

Applications

As the heart of a hydraulic system the pump drives single-acting cylinders and tools. The interactive pendant reports operation, programming and diagnostic status via LED and vibration pulses.
