High Tonnage Ultra Flat Hydraulic Cylinder, 5987 kN, 10 mm Stroke - Enerpac CUSP600

The CUSP600 delivers 5987 kN of force in minimal space. With a collapsed height of just 87.5 mm and a 10 mm stroke, this ultra-flat hydraulic cylinder works where standard cylinders no longer fit.

Benefits

• Extremely low collapsed height of 87.5 mm for confined spaces
• Integrated tilting function up to 4 degrees distributes the load and limits side load to up to 4 percent of rated capacity
• Nitrocarburized surface for enhanced corrosion protection in harsh conditions
• Red warning line clearly indicates the maximum permissible stroke
• Coupler CR400 including dust cap for quick connection to the pump

Technical data

• Capacity: 5987 kN
• Stroke: 10 mm
• Collapsed height: 87.5 mm
• Extended height: 97.5 mm
• Outside diameter: 386 mm
• Bore diameter: 330 mm
• Operating pressure: 700 bar
• Weight: 78.4 kg
• Series: CUSP

Applications

For high-tonnage lifting and pressing tasks in confined installation spaces. All ultra-flat cylinders require a solid, level bearing surface so the load is supported without settling.
