Double-acting compact cylinder to ISO 21287 with a 63 mm bore and 30 mm stroke. Anodised aluminium tube, stainless steel piston rod and a magnetic piston for contactless end-position sensing. Operating pressure up to 10 bar, G 1/8" port.
ISO 21287 Cylinder, double-acting, bore 63 mm, stroke 30 mm - Airtec NADA 63/30
AIRTEC Original product
Net price (excl. VAT)
€148.83 €125.07
Item FL-NADA-63/30
Manufacturer no. NADA 63/30
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.NADA 63/30
EAN4050571520212
Customs tariff number84123100
ConditionNeu
Artikel
FL-NADA-63/30
The Airtec NADA 63/30 is a double-acting compact cylinder to ISO 21287 with a 63 mm bore and 30 mm stroke. Its short overall length saves installation space in fixtures and handling systems, while the built-in magnetic piston lets cylinder switches of types D and A detect both end positions reliably.
Benefits
- Compact ISO 21287 design saves space at a 63 mm bore.
- Non-rotating stainless steel piston rod keeps alignment without an extra guide.
- Anodised aluminium tube for low weight and corrosion protection.
- Magnetic piston enables contactless end-position sensing with type D and A switches.
- Operating pressure up to 10 bar and a temperature range of -20 to +80 °C.
- Available with a male-threaded piston rod in the -AG version.
Technical data
| Bore diameter [mm] | 63 |
| Stroke [mm] | 30 |
| Design | compact per ISO 21287, double-acting |
| Piston rod | non-rotating |
| Head and foot | aluminium |
| Cylinder tube | anodised aluminium |
| Piston rod material | stainless steel |
| Seals | NBR / PUR |
| Medium | filtered compressed air |
| Operating pressure | max. 10 bar |
| Temperature range | -20 to +80 °C |
| Piston | with magnetic piston |
| Cylinder switch type | D, A |
| Air port G | G 1/8" |
| Repair kit | NAD 63 REP |
| A [mm] | 16 |
| B [mm] | 12 |
| BG [mm] | 13,8 |
| CH [mm] | 13 |
| D [mm] | 22 |
| D1 [mm] | 50 |
| D2 | M 6 |
| D3 [mm] | 6 |
| E [mm] | 77,0 |
| LA [mm] | 5,0 |
| RT | M 8 |
| TG [mm] | 56,5 |
| WH [mm] | 8 |
| ZA [mm] | 49 |
| ZC [mm] | 34 |
| ZD [mm] | 69 |
| Weight [kg] | 1.0 |
Applications
Suited to clamping, feeding and handling tasks in machine and fixture building, in assembly and packaging technology, and wherever a defined end-position signal is needed in a limited installation space.
Matching repair kit: NAD 63 REP.
| Hersteller-Nr | NADA 63/30 |
|---|---|
| Manufacturer | Airtec |
| EAN | 4050571520212 |
| Weight | 1.000000 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | AIRTEC Pneumatic GmbH, Westerbachstraße 7, DE-61476 Kronberg, www.airtec.de |
| Artikel-Authentizität | Originalprodukt |
| Artikelzustand | Neu |
| Position sensing | No |
